Description
The Saw Stop Contractor Saw offers versatility and safety. Whether on the job site or in the shop, it delivers the performance you need with the peace of mind only SawStop's patented safety system can provide.
- CONFIGURABILITY: Over 150 unique configurations, makes the Contractor Saw the most configurable SawStop saw. Adding a mobile base, sliding crosscut table or router table, are just a few of the ways to make this your ideal saw.
- UNIVERSAL PERFORMANCE: The Contractor Saw offers versatility, reliability and safety for a variety of users. The cast iron table top (Cast Iron Wing Assembly, CNS-CIWA, sold separately) creates a better-than-hybrid performance in the shop at an affordable price.
- SAWSTOP PATENTED SAFETY SYSTEM: Stops a spinning blade on contact with skin. The blade stops in less than 5 milliseconds, and drops below the table, minimizing a potentially life-altering injury to a mere scratch.
- RELIABILITY: The Control Box houses the on-off switch, power paddle, and on-board computer, and constantly checks that all systems are working to reliably keep you safe
Technical Data
| Motor Option(s) (60Hz TEFC): |
1.75 HP available
|
| Overall saw dimensions 30 in: |
58 1/2" W x 40" D x 34 3/4" H
|
| Motor Configuration(s): |
CNS175: 1.75 HP, 220v, 14 A
|
| Saw body footprint: |
25 3/4" W x 27" D (w/stand installed)
|
| Cast iron table: | 20″ W x 27″ D |
| Cast iron table (w/ extension wings): | 44″ W x 27″ D |
| Extension wings: |
12″ W x 27″ D Stamped Steel (optional cast iron for purchase)
|
| Shipping weights - w/ 30 in fence systems: |
268 lbs (2 boxes)
|
| Shipping dimensions (saw body only): |
35" W x 30" D x 20" H
|
| Shipping weight (approx.): |
240 lbs (table saw only)
|
| Assembled weights - w/ 30 in fence systems: | 245 lbs |
| Weights - table saw only: | 225 lbs |
| Weights - (optional cast iron wings): | 35 lbs each |
| Blade: |
40-tooth, prof. grade, 5/8″ arbor
|
| Blade diameter: | 10" |
| Blade tilt: | Left |
| Blade kerf: | 0.118″ (3mm) |
| Blade plate thickness: | 0.078″ (2mm) |
| Max. depth of cut, blade at 0º: | 3 1/8″ |
| Max. depth of cut, blade at 45º: | 2 1/4″ |
| Max. rip, left of blade (w/30” Std. Fence): | 16 1/2" |
| Max. rip, right of blade (w/30” Std. Fence): |
30 1/2" (w/Contractor Fence Assembly)
|
| Dado diameter: |
8" (requires dado brake cartridge & insert)
|
| Dado max. width: | 13/16" |
| Arbor diameter at blade: | 5/8" |
| Main bearing size: |
62mm OD x 30mm ID
|
| Second bearing size: |
52mm OD x 25mm ID
|
| Table in front of blade (max. elevation): | 10 5/8" |
| Table behind blade (max. elevation): | 7 1/8 |
| Arbor Runout: |
0.001″ Maximum allowable runout
|
| Table flatness measured diagonally: |
0.016″ Maximum gap
|
| Blade alignment with miter slot: |
0.010″ Maximum displacement
|
| Deviation of miter gauge indexing stops from actual: | ±0.25º |
| Alignment between splitter and blade: |
0.010″ Maximum difference
|
| Miter slots T-shaped: |
3/4″ at top, 1″ at bottom, 3/8″ deep
|
| Miter slots center: |
11 1/8″ center-to-center
|
| Miter slots info: |
5 1/2″ (arbor flange to center of right slot)
|
| Dust collection port diameter: | 4" |
| Riving knife / splitter thickness: | 0.090" (2.3 mm) |
| Blade guard: |
Standard polycarbonate, extends 1″ right of blade (opt dust guard for purchase)
|
| Insert: |
zero clearance, phenolic core, melamine surfaces
|
| Hand wheels: |
6″ diameter, cast alum. w/ ABS handle
|
| Belts: |
V-ribbed belt – static dissipative
|
Includes
(2) Steel Extension Wings
(1) Miter Gauge
(1) Micro Blade Guard
(1) Riving Knife
(2) Blade Wrenches
(1) Push Stick
(1) 10” Blade
(1) Table Insert
(1) Standard Brake Cartridge
(1) Owner’s Manual
(1) Assembly Instructions
(2) Hardware Packs
(1) 3mm Hex Key
(1) 5mm Hex Key
(1) 8mm hex Key
(1) Blade Spacing Adjustment Gauge
Fence Sold Separately
