Application:

A biscuit joiner is a woodworking tool used to join two pieces of wood together. In this case it would be used to join with the biscuit #20.

A biscuit joiner uses a small circular saw blade to cut a crescent-shaped hole in the opposite edges of two pieces of wood or wood composite panels.

An oval-shaped, highly-dried and compressed wooden biscuit (made from beech wood) is covered with glue, or glue is applied in the slot. The biscuit is immediately placed in the slot, and the two boards are clamped together. The wet glue expands the biscuit, further improving the bond.

Benefits:Power Tool Services

The grain direction on the biscuits are diagonal to add strength to the joinery.
The biscuit provides a quick means of getting a perfectly flush joint, while at the same time reinforcing the joint.

THE STANDARD SIZE OF A #0 BISCUIT:
LENGTH: 47mm
WIDTH: 15mm
THICKNESS: 4mm

THE STANDARD SIZE OF A #10 BISCUIT:
LENGTH: 53mm
WIDTH: 19mm
THICKNESS: 4mm

THE STANDARD SIZE OF A #20 BISCUIT:
LENGTH: 56mm
WIDTH: 23mm
THICKNESS: 4mm
