The D25601 is ideal for drilling anchor fixings and through holes in concrete and masonry from 12 to 45 mm in diameter. Core drilling up to 100 mm. Unique chain drive improves durability and efficiency together with an oil filled gearbox to ensure total lubrication and better heat dissipation. Active vibration control system reduces vibration.

Ideal for drilling anchor fixing and through holes in concrete and masonry from 12 to 45 mm in diameter. Core drilling up to 100 mm
Chain drive improves durability and increases efficiency together with an oil filled gearbox to ensure total component lubrication and superior heat dissipation
Active vibration control system incorporating a floating rear handle and damped side handle to reduce vibration
Ergonomic, compact and slim line design maximises control and offers easy access to confined spaces
Rotation-stop for medium-light demolition applications
Unique dust sealing protection to prevent even the finest dust ingress into the hammer mechanism delivering high durability and extended tool life
Hammer mechanism is optimised by reducing the number of components and by improving dampening to deliver maximum impact energy and therefore the efficiency to drill into the hardest concrete
Efficient mechanism delivers impact blows directly to the bit without losses through excessive vibration and rebound dampening reduces stress to the tool
Soft rubber grip handles improve user comfort lowering fatigue during extended use
Electronic variable impact energy/speed for total control with smaller bits and light material

More Information
GTIN	5035048236598
BRAND	DEWALT
RATING	Industrial
MOTOR TYPE	Brushed
HAMMER ACTION	With Hammer
CHUCK	SDS Max
MODE SELECTOR	3 Mode (Chipping)
INPUT POWER	1250W
OUTPUT POWER	615W
IMPACT ENERGY	8 Joules
NO LOAD SPEED (1ST)	210-415rom
IMPACT RATE (1ST GEAR)	1430-2840bpm
DRILLING CAPACITY [MASONRY]	45mm
OPTIMUM RANGE [CONCRETE]	25-35mm
BREAKTHROUGH BIT CAPACITY	65mm
CORE DRILL CAPACITY	100mm
CARRY CASE	Carry Case
WEIGHT (KG)	6.8000
