Description
The DHP490 is a powerful cordless hammer driver drill, equipped with an 18V LXT Li-Ion battery and a brushless motor. This tool delivers a maximum torque of 65 N·m and has a no-load speed of up to 1,900 rpm. Its lightweight and compact design makes it easy to handle, even in narrow spaces.
- Powerful brushless motor for longer work hours per charge and extended tool life
- 20-stage torque settings for fine adjustments
- Mechanical 2-speed gearing for choosing between maximum rpm or higher torque
- Three action modes: Drilling, Hammer drilling, and Screwdriving
- Single LED light with pre-glow and after-glow functions
- Variable speed trigger for speed adjustments based on the material or application
- Ergonomically designed grip for comfortable handling
- Keyless chuck for quick bit changes
- Water-resistance compatible with XPT
- Hook for easy and convenient hanging of the tool
- Battery protection circuit for protection against overloading, over-discharging, and over-heating
Technical Data
| Parameter | Value |
|---|---|
| No load speed: | High: 0 – 1,900 minˉ¹, Low: 0 – 500 minˉ¹ |
| Impacts per minute: | High: 0 – 28,500 minˉ¹, Low: 0 – 7,500 minˉ¹ |
| Capacity: | Masonry: 13 mm (1/2″), Steel: 13 mm (1/2″), Wood: 38 mm (1-1/2″) |
| Max torque: | 65 N·m (580 in.lbs) |
| Max fastening torque: | Hard: 50 N·m (440 in.lbs.), Soft: 27 N·m (240 in.lbs.) |
| Metal gear housing: | No |
| Chuck capacity: | 13 mm (1/2″) |
| Vibration level (EN62841-2-1): | Impact drilling into concrete: 8.1 m/s², Drilling into metal: 2.5 m/s² or less |
| Vibration K factor (EN62841-2-1): | Impact drilling into concrete: 1.5 m/s², Drilling into metal: 1.5 m/s² |
| Sound pressure level (EN62841-2-1): | 88 dB(A) |
| Sound power level (EN62841-2-1): | 96 dB(A) |
| Noise K factor (EN62841-2-1): | 3 dB(A) |
| Dimensions (L x W x H): | 172 x 81 x 237 mm (6-3/4 x 3-3/16 x 9-3/8″) |
| Net weight: | 1.4 – 1.7 kg (3.1 – 3.7 lbs.) |
| Net weight (Battery): | BL1815N – BL1860B |
Includes
- 1x DHP490 Cordless Hammer Driver Drill in Cardboard Box
