Description
Compact and durable, the US8016 series delivers the best-in-class performance for a variety of fine wire stapling applications. With a robust motor and ergonomic design, this tool works all day, every day and won't snag or scuff fabric
- REAR ADJUSTABLE DIRECTIONAL EXHAUST - Accommodates different working environments
- RAPID CYCLING ENGINE - Fast cycle time boosts efficiency
- SAFETY OPTION - Optional safety double trigger
- RAPID CYCLING ENGINE - Fast cycle time boosts efficiency
- EAZY-ACCESS MAGAZINE LATCH - One-hand manual rear latch
- ALL METAL MEGAZINE - Robust construction endures rough production settings
- SPEED-ADJUSTABLE AUTOMATIC VERSION AVAILABLE - Switch between single fire mode and automatic mode with ease on flexible speed settings
- EXTRA LONG NOSE AVAILABLE - 50mm (2") nose helps tackle applications with hard-to-reach spots
Technical Data
| Weight |
Standard Magazine: 0.9 kgs (2.0 lbs)
Long Magazine (ALM): 1.2 kgs (2.6 lbs) |
| Height |
Standard Nose: 140mm (5.5")
Long Nose (LN): 197mm (7.8") |
| Width |
38mm (1.5")
|
| Length |
Standard Magazine: 197mm (7.8")
Long Magazine (ALM): 380mm (15") |
| Operating Pressure |
5~6.9 bar (70~100 psi)
|
| Driving Power (in-lbs @100psi) | 51 |
| Air Consumption (L/sec @90psi) |
0.3 (0.64 cfm)
|
| Type |
21 GA. 80 Series / Senco AT
|
| Loading Capacity | 100 ~ 180 |
| Shank Type | Smooth |
| Staple Length |
5~16mm (3/16"~5/8")
|
| Staple Crown Width |
12.8mm (1/2")
|
| Staple Wire Dia. |
0.63x0.90mm (0.025"x0.036")
|
Includes
1x Fine Wire Stapler
