Description
The Bosch Professional Slide Mitre Saw GCM 254 D 0601B53000 offers long-lasting accuracy and precision in every cut. With a highly visible laser line, consistently accurate cuts are easily achieved. The detachable box extension provides better support for various material cutting, while the length gauge allows for easier multiple repeating cuts. With a 310 mm sliding capacity, this saw is perfect for larger cuts with superior precision.
- Highly visible laser line for consistently accurate cuts
- Detachable box extension for better support in various material cutting
- Length gauge for easier multiple repeating cuts
- 310 mm sliding capacity for larger cuts with superior precision
- Long-lasting accuracy in every cut
Technical Data
| Saw blade diameter | 254 mm |
| Saw blade bore diameter | 30 mm |
| Rated input power | 1.800 W |
| Sound pressure level | 98 dB(A) |
| Sound power level | 109 dB(A) |
| Uncertainty K | 3 dB |
| Cutting capacity, 0° | 90 x 310 mm |
| Cutting capacity, 45° mitre | 90 x 210 mm |
| Cutting capacity, 45° bevel | 45 x 310 mm |
| Mitre setting | 47° L / 52° R |
| Bevel setting | 45° L / 45° R |
| Tool dimensions (width x length x height) | 574 x 779 x 645 mm |
| No-load speed | 4,800 rpm |
| Weight | 17.9 kg |
Includes
1 x circular saw blade, Optiline Wood, 254 x 2.8/1.8 x 30 mm, 40 2 608 640 443
Dust bag 1 619 PB6 246
Supporting box 1 619 PB9 050
