Description
This medium-sized, floor-standing pillar drill offers exceptional strength, reliability, and stability with its cast iron and machined steel construction. Powered by a smooth-running 750W induction motor, it delivers 12 belt speeds ranging from 120 to 2,580rpm, ensuring versatile performance for various drilling tasks. Equipped with a high-accuracy chuck spindle assembly running on NSK ball bearings, this drill is ideal for trade or professional workshops. Safety features include an interlocked chuck guard, emergency stop switch, and belt cover safety switch. A rack and pinion system allows for easy table height adjustment, and the table can swivel to enable the base as a work support.
- Smooth-running 750W induction motor with low vibration
- 12 belt speeds ranging from 120 to 2,580rpm
- Rack and pinion table height adjustment for convenience
- High-accuracy chuck spindle assembly with NSK ball bearings
- Electrically interlocked chuck guard for enhanced safety
- LED work lamp for improved visibility
- One-piece cast iron handle with soft rubber grips
- Swivelling table for versatile work support
| Power | 750 W |
| Voltage | 230 V |
| Speed Range | 120 – 2,580 rpm |
| Chuck Capacity | 1 mm to 16 mm |
| Chuck Type | Keyless |
| Chuck Travel | 80 mm |
| Max Drilling Capacity (Mild Steel) | 25 mm |
| Max Chuck to Table | 700 mm |
| Max Chuck to Base | 1,150 mm |
| Throat Depth | 216 mm |
| Table Size | 345 mm x 345 mm |
| Table Tilt | 45° – 0° – 45° |
| Base Size | 520 mm x 320 mm |
| Column Diameter | 80 mm |
| Overall Dimensions (L x W x H) | 750 mm x 430 mm x 1,650 mm |
| Weight | 108 kg |
Includes
- 1x Floor Standing Pillar Drill
- 1x 1-16mm Keyless Chuck
- 1x LED Work Lamp
