Description
The Kreg Cabinet Hardware Jig KHI-PULL-INT takes the guesswork out of installing cabinet knobs and pulls. The moveable edge guide and measuring scales make it easy to position knobs precisely, while adjustable drill guides ensure straight holes for perfect knob and pull positioning every time. Perfect for new construction and for refreshing entire rooms
- Adjustable guides for accurate hole placement
- Built-in measuring scales for repeatable results
- Versatile for mounting single and multi-hole knobs
- Adjustable edge guide for easy positioning
- Strong, lightweight materials for easy handling
- Durable hardened-steel drill guides
Technical Data
| Construction |
Durable polymer
|
| Drill Guides |
Two movable 3/16" (4.5mm) guides with locking nuts
|
| Drill Guide Material |
Hardened Steel
|
| Drill Guide Spacing |
21/2", 3", 31/2", 4", 41/2", 5"
and 64mm, 96mm, 128mm |
| Edge Guide to Hole-Center Spacing |
1" to 5" (25mm-127mm)
|
| Measuring Scales |
Imperial and Metric
|
Includes
(1) jig base
(1) edge guide
(2) drill guides with knurled nuts
(2) non-slip pads
(2) T-knobs and bolts
owner’s manual
3/16" (5mm) drill bit required - does not come included.
