Description
The CTL 48 EC/B22 special extractor with EC-TEC drive is suitable for continuous operation. The robust ABS plastic container is equipped with additional flame protection and is therefore suitable for the safe extraction of aluminium, paper, soot and powder coating dust right through to glass and carbon-reinforced plastics. Thanks to the powerful, durable and brushless EC-TEC motor and its huge container capacity of 48 l, the CLEANTEC CTL 48 LE EC/B22 is ideal for use in industrial environments. Its large container geometry provides maximum volume. The swivelling castor wheels, rear wheels and handle also make it extremely mobile. The flat filter fully integrated in the suction head ensures the full volume is utilised: This means that the gross and net container volumes are virtually identical. The extremely compact high-performance turbine provides the right suction power. A 3900 l/min volume flow means that nothing remains except clean air. Approved for dusts in dust class L.
- Conforms with ATEX Directive 2014/34/EU for Zone 22 – dry, combustible dust on machines and tools is reliably extracted
- Constant power from the EC-TEC drive with a service life several times longer than a universal motor
- With a new suction hose: Smooth and flexible – with a smooth exterior which allows it to slide over surfaces perfectly
- With integrated connection for EAA and compressed air tools
- Antistatic function: Prevents static developing during work.
- Cable holder to keep things tidy
- Approved for dust category L
- Economical because of the optimal use of the available volume with a SELFCLEAN filter bag in the container
- compressed air connection with additional air flow -I/O- Automatic
- EAA connection
Technical Data
| Power consumption | 150 – 1 100 W |
| Max. volume flow | 3400.00 l/min |
| Max. vacuum | 23000.00 Pa |
| Filter surface area | 6318.00 cm² |
| Rubber-insulated mains cable | 7.50 m |
| Container/filter bag capacity | 48/46 l |
| Dimensions (L x W x H) |
630 x 406 x 640 mm
|
| Max. appliance socket connected load | 2400.00 W |
| Dust class | L |
| Cable length | 7.50 m |
| Product weight without accessories | 19.50 kg |
| Transport weight incl. accessories | 25.20 kg |
| Drive type | Mains |
Includes
Main filter HF-CT 26/36/48
SELFCLEAN filter bag
Suction hose D 27/32x3,5m-AS/CTR
Compressed air module DL CT 26/36/48
